DIN Rail Single Phase Split Prepayment Energy Meter ine Pazasi Wiring

Type:
DDSY283SR-SP46

Muchidimbu
DDSY283SR-SP46 chizvarwa chitsva chemberi-chikamu-mbiri-waya, yakawanda-inoshanda, yakapatsanuka-mhando, mbiri-yedunhu metering prepaid simba mita.Inonyatsoenderana neSTS standard.Inogona kupedzisa bhizinesi rekubhadhara kare uye kuderedza kurasikirwa kwechikwereti kwekambani yemagetsi.Iyo mita ine yakanyanya kurongeka, yakaderera simba rekushandisa, uye CIU kuratidza unit, iri nyore kuti vashandisi vashande.Iyo kambani yemagetsi inogona kusarudza akasiyana midhiya yekutaurirana kuti itaure neiyo data concentrator kana CIU zvinoenderana nezvinodiwa kwavari, sePLC, RF uye M-Bus.Inokodzera vashandisi vekugara uye vekutengesa.


Product Detail

Product Tags

Simbisa

MODULAR-DESIGN
MODULAR DESIGN
MULTIPLE COMMUNICATION
MULTIPLE COMMUNICATION
ANTI-TAMPER
ANTI TAMPER
TIME OF USE
NGUVA YEKUSHANDISA
REMOTE  UPGRADE
REMOTE UPGRADE
RELAY
RELAY
HIGH PROTECTION DEGREE
KUDZIVIRIRA KWAKUKURU KWEDEGREE

Zvinotsanangurwa

Item

Parameter

Basic Parameter

Kunyatsoita basa:Kirasi 1 (IEC 62053-21)

Reactive kunyatsoita:Kirasi 2 (IEC 62053-23)

Rated voltage: 220/230/240V

Yakatarwa mashandiro emhando: 0.5Un~1.2Un

Chiyero chazvino:5(60)/5(80)/10(80)/10(100)A

Kutanga ikozvino: 0.004Ib

Frequency: 50/60Hz

Pulse constant:1000imp/kWh 1000imp/kVarh (inogadziriswa)

Azvino redunhu simba rekushandisa <0.3VA

Voltage redunhu simba rekushandisa <1.5W/3VA

Kushanda tembiricha siyana: -40°C ~ +80°C

Kuchengetedza tembiricha: -40°C ~ +85°C

Type Testing

IEC 62052-11 IEC 62053-21 IEC 62053-23 IEC 62055-31

Kukurukurirana

Optical port

RS485/M-Bhazi

PLC/G3-PLC/HPLC/RF

IEC 62056/DLMS COSEM
Kuyera Zvinhu zviviri

Simba:kWh,kVarh,kVAh

Pakarepo:Voltge,Irizvino,Simba rinoshanda,Simba rinoshanda,Simba rinoonekwa,Simba remagetsi,Voltage current angle, Frequency

Tariff Management

8 mutero, 10 zuva nezuva nguva, 12 mazuva masheti, gumi nemaviri masheti evhiki, 12 mwaka wemwaka, 100 mazororo (inogadziriswa)

LEDDisplay Active simba kupomba,Reactive simba kupomba,

Chimiro chechikwereti chasara,

CIU kutaurirana / Alarm mamiriro

RTC

Kunyatsoita wachi:≤0.5s/zuva (mu23°C)

Zuva rekuchengetedza nguva: Inogadziriswa kana otomatiki switching
Bhatiri remukati (risingatsivike) Hupenyu hunotarisirwa angangoita makore gumi nemashanu
Chiitiko Chiitiko chakajairwa,Chiitiko cheSimba,Chiitiko chakakosha,etc.Chiitiko zuva nenguva

Kanenge zana rekodhi rekodhi rondedzero

Storage NVM, angangoita makore gumi nemashanu
Chengetedzo DLMS chikamu 0

Prepayment Basa

STS standardPrepayment mode:Magetsi/Mari
Chajazve: CIU Keypad (3*4) Chajazve ne20-manhamba STS tokeni
Yambiro yechikwereti:Inotsigira nhanho nhatu dzeyambiro yechikwereti.The level threshold is configurable.

Chikwereti cheEmergency: Mutengi anokwanisa kuwana mari shoma yechikwereti sechikwereti chenguva pfupi.

Zvinogoneka.

Hushamwari mode:Inoshandiswa mumamiriro ezvinhu asina kunaka kuti uwane chikwereti chinodiwa. Iyo modhi inogadzirika.Semuyenzaniso, husiku kana kuti mune asina kusimba mutengi)

Mechanical Kuiswa:RAIL
Dziviriro yakavharirwa: IP54
Tsigira kuiswa kwezvisimbiso
Meter Nyaya: Polycarbonate
Dimensions (L*W*H):155mm*110mm*55mm
Kurema: Approx.0.55kg
Yekubatanidza wiring Muchinjikwa-chikamu nzvimbo: 2.5-35mm²
Mhando yekubatanidza: LNNL/LLNN
CIU
LED & LCD kuratidza Chiratidzo che LED: Yakasara kiredhiti chimiro, Kukurukurirana, Chiitiko / Relay mamiriro
LCD kuratidza: Zvakafanana neMCU kuratidza
Mechanical Dziviriro yakavharirwa: IP51
Nyaya yezvinhu: Polycarbonate
Dimension (L*W*H):148mm*82.5mm*37.5mm
Kurema:Approx.0.25kg
